BeamPro Square Format Laser Beam Profiler
BeamPro Square Format Laser Beam Profiler
beampro-2
beampro-3
BeamPro Square Format Laser Beam Profiler
BeamPro Square Format Laser Beam Profiler

BeamPro | Square Format Laser Beam Profiler

Smallest pixel pitch

2.74 µm

Largest active area

12.3 x 12.3 mm

Bit depth

12/16-bit (with HDR option)

Interface

USB3.1

Software

STAR software + Web API

Options

UV, trigger, windowless, vacuum compatible

BeamPro square format Laser Beam Profiler

Beam profiler with the most natural shape for circular beams

Femto Easy BeamPro beam profilers are available with the widest range of square sensors, even offering the ultimate combination of small pixels, large area and global shutter in a single device.

The Femto Easy BeamPro takes advantage of our user-friendly software, and provides thorough analysis and statistics of your laser beam. The BeamPro software uses standard communication protocols. It is therefore easily integrable in most complex environments. Several BeamPro can be controlled from a remote screen through network. They are suitable for wavelength from 190 to 1100 nm and sensor size is up to 25 mm. There are also high resolution models with pixels as small as 1.45 μm for focused beam measurements.



BeamPro square format Laser Beam Profiler

Beam profiler with the most natural shape for circular beams

Femto Easy BeamPro beam profilers are available with the widest range of square sensors, even offering the ultimate combination of small pixels, large area and global shutter in a single device.

The Femto Easy BeamPro takes advantage of our user-friendly software, and provides thorough analysis and statistics of your laser beam. The BeamPro software uses standard communication protocols. It is therefore easily integrable in most complex environments. Several BeamPro can be controlled from a remote screen through network. They are suitable for wavelength from 190 to 1100 nm and sensor size is up to 25 mm. There are also high resolution models with pixels as small as 1.45 μm for focused beam measurements.

  • Compact design
  • Marker indicating chip location
  • Two wavelength ranges available
  • Neutral Density filters available
  • C-mount
  • Windowless option available
  • Custom versions available on request
  • User-friendly and powerful software (STAR : Software Technology for Acquisition and Retrieval)

Axiom Optics offers additional models of the BeamPro which can be found here.

You can also visit the manufacturer’s website: www.femtoeasy.eu

1

Sensor size up to 12.3mm
2

Spectral range: 375-1100nm (190nm with UV option)
3

CW and pulsed lasers
4

USB3.1 interface
5

Free STAR software
